Handheld 1500W Laser Welding Machine With Function Of Cleaning And Cutting
Interduction
The compact and flexible MINI RL-Y1500 portable handheld laser welding machine has been deeply loved by customers since its development. It has an integrated structure with built-in integrated control system, laser system and cooling system. Easy to carry, good welding effect, many cleaning modes, good cutting effect.
Simple to operate, ready to use. . The hand-held laser welding machine adopts an ergonomically designed hand-held laser welding head, and the welding head with a control screen is optional, which is more convenient and practical.
Specification
| Laser Beam | 1500watt GW Continuous Wave Fiber Laser,Emission Wavelength 1080±5nm |
| Cooling | Built-in Industrial Chiller(Purified water or distilled water) |
| Cable length | Fiber cable lenght 10m, Operable cable length 8m |
| Cleaning head | 0.75kg cleaning head |
| Wobble width | Adjustable 20-100mm |
| Protection Gas | compressed gas Pressure 5-10L/min |
| User Interface | For Laser Control:Power,Frequency, Frequency,Spot width |
| Language | Chinese-English |
| Safty | Class 4 laser equipment,Machine with CE,FDA certificate. |
| The machine comes with error alarm function,emergency stop,chiller alarm. |
| Power Requirement | 220±10% V AC, 50/60Hz |
| Operating Ambient Temperature(℃) | 10~40℃ |
| Humidity (%) | 90 |
| Dimensions(W×H×D) | 745*516*710mm |
| Weight | 160kg
|
Main components of this machine
Automatic wire feeder
Automatic wire feeder for seam welding less than 1.6mm
adjustable speed
Wire coil weight less than 15kg
Wire diameter 0.8, 1.0, 1.2, 1.6mm, aluminum 1.2mm
Support welding methods
Laser head
With 6 light spot modes (O, ●, 8, ◎, -, △)
The spot size can be adjusted from 0.2-5mm,
Simple operation, fingertip digital selection and adjustment
Can significantly improve welding efficiency.
Can be equipped with automatic wire feeding device
Water cooling device
Built-in industrial chiller, no external chiller required
Built-in water temperature alarm function, safe production
Dual temperature dual control
Packing details
Machine Video
